Neith Metals, located in Cairo, Egypt, has built a solid reputation as a reliable manufacturer and supplier of Aluminium 5083 Bars and Rods. These products are celebrated for their impressive strength, resistance to corrosion, and outstanding performance in both marine and industrial settings. With a strong foothold in the metal industry, Neith Metals is committed to delivering top-notch aluminium products that adhere to both national and international standards. Their Aluminium 5083 Bars and Rods are crafted using cutting-edge technology and rigorous quality control measures, ensuring they are both dependable and durable. Neith Metals caters to a wide array of clients across different sectors, providing customized sizes and prompt delivery to meet unique project needs.
Aluminium 5083 Bars and Rods are primarily made up of aluminium (about 93–95%), along with significant amounts of magnesium (4.0–4.9%), manganese (0.4–1.0%), and trace elements such as chromium, iron, silicon, and titanium. This alloy boasts excellent mechanical properties, featuring a typical tensile strength ranging from 270 to 350 MPa and a yield strength of around 215 MPa. It also offers good ductility and is easy to weld, even after being exposed to harsh marine or chemically aggressive environments. These traits make Aluminium 5083 a top choice for structural and load-bearing applications that demand high strength and corrosion resistance.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Weight% | Al | Si | Fe | Cu | Mn | Cr | Mg | Ti | Zn | Other Each | Others Total |
| 5083 | Bal | 0.40 max | 0.40 max | 0.10 max | 0.40 / 1.0 | 0.05 / 0.25 | 4.0 / 4.90 | 0.15 max | 0.25 max | 0.05 max | 0.15 max |
| Properties | Proof Stress | Tensile Strength | Hardness Brinell | Elongation |
| Metric | 125 Min MPa | 275 – 350 MPa | 75 HB | 12 Min % |
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) |
| AW-AlMg4,5Mn0,7 | AG4,5MC | 3.3547 | A95083 | AlMg4,5Mn0,7 | 5083 | AlMg4,5Mn |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 5083 bars are fully recyclable. Recycling preserves the material's properties, reduces energy consumption, and minimizes environmental impact, making it an eco-friendly choice for sustainable manufacturing.
To maintain Aluminium 5083 bars, regularly clean them with mild detergent and water to prevent corrosion. Avoid abrasive materials, and apply protective coatings if exposed to harsh environments for enhanced durability.
When installing Aluminium 5083 bars and rods, consider proper welding techniques, corrosion protection, accurate measurements, compatibility with other materials, and ensuring proper handling to avoid surface damage or distortion.
Aluminium 5083 Bars and Rods find extensive use in industries that require strength and durability in tough conditions. Their remarkable resistance to corrosion in marine and saltwater environments makes them perfect for shipbuilding, offshore platforms, and coastal structures. In the transportation sector, they are utilized for crafting fuel tanks, truck bodies, and railcars, thanks to their lightweight yet robust nature. The alloy’s excellent weldability and formability also render it suitable for pressure vessels and cryogenic storage tanks. Furthermore, they are employed in aerospace, defense, and chemical processing applications, where maintaining structural integrity and long-term performance is crucial.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
