Neith Metals, located in Cairo, Egypt, stands out as a top manufacturer and supplier of high-quality specialty alloys and metal products. Among their standout offerings are Hastelloy Bars and Rods, which are celebrated for their remarkable corrosion resistance, impressive strength, and durability in harsh chemical and high-temperature settings. Crafted with cutting-edge metallurgical techniques and rigorous quality control, these bars and rods adhere to international standards for precision and reliability. Neith Metals caters to various industries, including chemical processing, petrochemical, marine, and power generation, providing robust Hastelloy Bars and Rods that are built to ensure long-lasting performance, operational efficiency, and safety in demanding industrial environments.
Hastelloy Bars and Rods are nickel-based alloys primarily made up of nickel, molybdenum, and chromium, with trace amounts of iron, cobalt, and carbon to boost their mechanical properties and corrosion resistance. These bars and rods showcase excellent tensile strength, typically falling between 550–750 MPa, and a yield strength of around 240–350 MPa. With outstanding hardness, toughness, and resistance to pitting, crevice corrosion, and both oxidizing and reducing environments, Hastelloy maintains its mechanical integrity even under extreme conditions, making it perfect for critical and high-performance industrial applications.
| Dimensions | DIN, EN, ASTM, JIS, ASME, BS, AISI |
|---|---|
| Hastelloy Round Bar size | Diameter: 3-~800mm |
| Hastelloy Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Hastelloy Bar Angle size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Rectangular Bars Section | 3.0 to 12.0mm thickness |
| Billet Size | 1/2 to 495mm Diameter |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Dimensions | Diameter / Height |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Surface | Hot Rolled Pickled, Bright, Sand Blasting Finished, Cold Drawn, Hairline,Polished |
| Condition | Hardened & tempered, annealed |
| Technique | Stainless Steel Cold Drawn, Hot Rolled, Forged Round Bar,Cold Rolled, Rod |
| Processing | Bar cutting to 650mm |
| Form | Rod, Round, Channel Bar, T-Bar, Flat Bar, Precision Ground Bar, Blocks, Square, Rings, Round Rod, Triangle, Hollow, Rectangle, Threaded, Hex (A/F), Profiles, Half Round Bar, Ingot, Billet, I/H Bar, Forging etc. |
| Grade | UNS | Cr | Mo | Fe | C≤ | Si≤ | Co≤ | Mn≤ | P≤ | S≤ |
| B2 | N10665 | 1.0max | 26.0-30.0 | 2.0max | 0.02 | 0.10 | 1.0 | 1.0 | 0.04 | 0.03 |
| B3 | N10675 | 1.0-3.0 | 27.0-32.0 | 1.0-3.0 | 0.01 | 0.10 | 3.0 | 3.0 | 0.03 | 0.01 |
| X | N06002 | 20.5-23.0 | 8.0-10.0 | 17.0-20.0 | 0.05-0.15 | 1.0 | 0.5-2.5 | 1.0 | 0.04 | 0.03 |
| C22 | N06022 | 20.0-22.5 | 12.5-14.5 | 3.0-6.0 | 0.015 | 0.08 | 2.5 | 0.5 | 0.02 | 0.02 |
| C2000 | N06200 | 22.0-24.0 | 15.0-17.0 | 3.0max | 0.01 | 0.08 | 2.0 | 0.5 | 0.025 | 0.01 |
| C276 | N10276 | 14.5-16.5 | 15.0-17.0 | 4.0-7.0 | 0.01 | 0.08 | 2.5 | 1.0 | 0.04 |
| Mechanical properties | Tensile, min, ksi[MPa] | Yield, min, ksi[MPa] | Elongation, %(min) |
| B2 | 110[760] | 51[350] | 40 |
| B3 | 110[760] | 51[350] | 40 |
| X | 100[690] | 40[276] | 35 |
| C22 | 100[690] | 45[310] | 45 |
| C2000 | 100[690] | 45[310] | 45 |
| C276 | 100[690] | 41[283] | 40 |
Yes, Hastelloy Bars are highly corrosion-resistant, making them ideal for harsh environments, including chemical processing and marine applications. They resist pitting, crevice corrosion, and stress corrosion cracking effectively.
Yes, Hastelloy Rods can be customized in size and length to meet specific industry requirements. Their versatility ensures suitability for diverse applications.
Hastelloy bars perform exceptionally in high-temperature environments, offering thermal stability, oxidation resistance, and strength retention. They are ideal for demanding applications like chemical processing and aerospace.
Hastelloy Bars and Rods find extensive use in industries that demand superior corrosion resistance and mechanical strength. They are particularly suited for chemical reactors, heat exchangers, storage tanks, and piping systems that come into contact with aggressive acids and oxidizing agents. Petrochemical, pharmaceutical, and food processing facilities utilize Hastelloy for valves, pumps, and fasteners that require long-term reliability. Marine and offshore applications depend on these bars and rods for components that face seawater and industrial fluids. Furthermore, power generation and industrial machinery rely on Hastelloy to guarantee durability, safety, and consistent performance in highly demanding operational conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
