Neith Metals, located in Cairo, Egypt, stands out as a top manufacturer and supplier of high-quality Aluminium 5086 Bars and Rods. Known for their precision, durability, and dependable service, Neith Metals serves a variety of industries by providing aluminum products that adhere to international standards. The Aluminium 5086 alloy is particularly praised for its outstanding corrosion resistance, especially in marine settings, making it a go-to choice for shipbuilding and structural projects. Neith Metals is dedicated to delivering premium materials, supported by technical know-how and prompt delivery, to aid infrastructure, transportation, and industrial initiatives across Egypt and the wider Middle East.
Aluminium 5086 Bars and Rods are primarily made of aluminum, with magnesium being the main alloying element (around 3.5%–4.5%), along with trace amounts of chromium, iron, and silicon. This blend boosts strength while keeping corrosion resistance intact. In terms of mechanics, Aluminium 5086 boasts a tensile strength ranging from 240 to 330 MPa, along with excellent elongation and weldability. It performs well in both hot and cold working conditions and retains its strength even in extreme cold. These characteristics make Aluminium 5086 a fantastic option for applications that demand both structural integrity and resistance to environmental factors.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| GRADE | Si | Ir | Cu | Mn | Mg | Cr | Zn | Ti | Others, each | Others, total | Al |
| 5086 | 0.4 | 0.5 | 0.1 | 0.20-0.70 | 3.5-4.5 | 0.05-0.25 | 0.25 | 0.15 | 0.05 | 0.15 | Balance |
| Properties | Proof Stress | Tensile Strength | Hardness Brinell | Elongation |
| Metric | 125 Min MPa | 275 – 350 MPa | 75 HB | 12 Min % |
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) |
| AW-AlMg4 | AG4MC | 3.3545 | A95086 | AlMg4 | 5086 | AlMg4Mn |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 5086 bars are fully recyclable. Aluminium is a sustainable material that can be recycled repeatedly without losing its properties, making it an environmentally friendly option for various applications.
Yes, Aluminium 5086 bars and rods can be used for potable water applications due to their corrosion resistance and durability, making them suitable for marine environments and water treatment systems.
When installing Aluminium 5086 bars and rods, consider factors such as proper handling to avoid damage, ensuring compatibility with other materials, and protecting against corrosion by using appropriate coatings or finishes.
Aluminium 5086 Bars and Rods find their place in industries where corrosion resistance, strength, and lightweight features are essential. In the marine sector, they are frequently used in ship hulls, boat decks, and various offshore structures due to their ability to withstand seawater corrosion. The automotive and aerospace industries also rely on them for structural frames and support components. Additionally, they are utilized in pressure vessels, cryogenics, and defense equipment. Their excellent weldability and formability make them ideal for architectural frameworks and transportation applications. Neith Metals provides these versatile products to satisfy the rigorous demands of both local and international markets.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
