Neith Metals, located in Cairo, Egypt, stands out as a top-notch manufacturer and supplier of high-quality Stainless Steel 304 Hex Bars and Rods. Known for their precision engineering and cutting-edge production methods, they strictly adhere to international quality standards. Neith Metals offers stainless steel products that are not only strong and durable but also resistant to corrosion. Their Stainless Steel 304 Hex Bars and Rods are designed to perform exceptionally well in tough industrial settings. Catering to sectors like chemical processing, construction, food production, and marine, Neith Metals guarantees reliable, long-lasting, high-performance stainless steel solutions tailored to the needs of both local and global clients.
These Stainless Steel 304 Hex Bars and Rods are primarily made up of chromium (18–20%) and nickel (8–10.5%), which provide outstanding corrosion resistance and durability. They also include trace amounts of carbon, manganese, silicon, phosphorus, and sulfur, all of which enhance their mechanical properties and workability. This alloy boasts a minimum tensile strength of 515 MPa, a yield strength of at least 205 MPa, and an elongation of around 40%. With remarkable toughness, ductility, and formability, these hex bars and rods excel in welded and fabricated components across a variety of industrial applications.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 304 | 8.0 – 11.0 | 18.0 – 20.0 | 2.0 max | 8.0 – 11.0 | 0.045 max | 0.03 max | 1.0 max |
| Element | Tensile Strength | Yield Strength | Elongation | Reduction in Area | Hardness |
| SS 304 | Psi – 85,000 | Psi – 45,000 | 50% | 55% | Rb 180 |
| Element | Density, lb/in3 | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| SS 304 | 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Standard sizes for SS 304 hex bars/rods typically range from 1/8" to 6" in diameter. Custom sizes, lengths, and finishes are generally available upon request, depending on the supplier's capabilities and production methods.
SS 304 hex bars/rods can be welded and fabricated into complex shapes with relative ease. It offers good weldability, but pre-welding surface preparation and proper techniques are necessary to avoid distortion or degradation of material properties.
SS 304 offers good strength and corrosion resistance, suitable for many applications. Compared to other grades like SS 316, it has slightly lower corrosion resistance, especially in chloride environments, but SS 304 is more cost-effective and widely used.
Neith Metals’ Stainless Steel 304 Hex Bars and Rods are extensively utilized in industries that demand corrosion resistance, strength, and precision. They’re perfect for chemical tanks, pressure vessels, piping systems, heat exchangers, and food processing equipment. Their hexagonal shape makes them easy to grip, machine, and assemble, making them ideal for shafts, fasteners, mechanical components, and parts for industrial machinery. Additionally, they find applications in marine, architectural, and automotive fields where long-term durability and reliability are crucial. Stainless Steel 304 Hex Bars and Rods offer versatile and dependable solutions for essential engineering projects.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Neith Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Alexandria, Egypt
