Neith Metals, based in Cairo, Egypt, has earned a solid reputation as a reliable manufacturer and supplier of top-notch Stainless Steel 304H Bars and Rods. With a focus on precision engineering and cutting-edge production techniques, they strictly adhere to international quality standards. This commitment ensures that their stainless steel products deliver outstanding strength, durability, and resistance to high temperatures. The Stainless Steel 304H Bars and Rods from Neith Metals are specifically crafted to perform consistently in tough industrial settings. They cater to various sectors, including petrochemical, power generation, chemical processing, and construction, providing high-performance stainless steel solutions that meet the essential needs of both local and global customers.
These Stainless Steel 304H Bars and Rods are primarily made up of chromium (18–20%) and nickel (8–10.5%), with a higher carbon content (0.04–0.10%) that boosts strength at elevated temperatures. They also include trace amounts of manganese, silicon, phosphorus, and sulfur, which enhance their mechanical performance and workability. This alloy boasts impressive tensile strength ranging from 515 to 700 MPa, yield strength between 205 and 310 MPa, and an elongation of about 40%. Thanks to their superior toughness, heat resistance, and corrosion resistance, these bars and rods are perfect for high-temperature industrial applications.
| Grade | Stainless Steel 304H (UNS S30409) |
|---|---|
| Specification | ASTM A276, ASTM A479 |
| Round bar size | Diameter: 3-~800mm |
| Hex Bar size | 2-100mm A/F |
| Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Hollow Bar | 32 OD x 16 ID to 250 OD x 200 ID |
| Square bar size | 4 to 100mm |
| Section | 3.0 to 12.0mm thickness |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Billet Size | 1/2″ to 495mm Diameter |
| Channel Bar | 80 x 40 to 150 x 75 mm section; 5 to 6 mm thickness |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Angle bar size | 3*20*2~12*100*100 mm |
| Form | Rings, Profiles, Hollow, Flat Bar, Square, Round, Rectangle, Triangle, Rod, Half Round Bar, T-Bar, Hex (A/F), Precision Ground Bar, Channel Bar, Blocks, Round Rod, Threaded, Billet, Ingot, I/H Bar, Forging etc. |
| Technique | Cold Drawn, Rod, Hot Rolled, Cold Rolled, Forged Round Bar |
| Condition | annealed, Hardened & tempered |
| Surface | Cold Drawn, Polished, Bright, Hot Rolled Pickled, Sand Blasting Finished,Hairline |
| Element | SS 304H |
| C | 0.10 max |
| Ni | 8.0 – 10.5 |
| P | 0.045 max. |
| Mn | 2.00 max |
| Si | 0.75 max |
| S | 0.03 max. |
| Cr | 18.0 – 20.0 |
| Element | SS 304H |
| Melting Point | 1400 ℃ |
| Density | 8 |
| Hardness (Brinell) | 201 |
| Yield Strength (0.2%Offset) | 205 |
| Tensile Strength | 515 |
| Elongation | 40 |
|
Type |
SIZES (Inches) |
ISO Tolerance |
SIZES (mm) |
|---|---|---|---|
|
Peeled and Polished |
1.50″ to 6.00″ |
h11-DIN 1013 |
40.00 to 150.00 |
|
Cold Drawn and Ground |
5/6″ to 2.50″ |
h9-h8-h11-h10 |
10.00 to 75.00 |
|
Cold Drawn and Polish |
1/8″ to 3.00″ |
h9-h8-h11-h10 |
3.00 to 75.00 |
|
Peeled and Ground |
3/4″ to 2.00″ |
h10-h9-h11 |
20.00 to 50.00 |
| STANDARD | UNS | WERKSTOFF NR. |
| SS 304H | S30409 | 1.4301 |
Stainless Steel 304H has a higher carbon content (0.04–0.10%), which enhances its strength and heat resistance, making it suitable for high-temperature applications compared to 304 and 304L.
Industries such as petrochemical, power generation, chemical processing, and construction use Stainless Steel 304H for applications like heat exchangers, boilers, pressure vessels, and structural components.
Yes, Stainless Steel 304H is designed for excellent performance in high-temperature environments, maintaining strength and corrosion resistance in conditions up to 870°C (1600°F).
Neith Metals’ Stainless Steel 304H Bars and Rods find extensive use in situations that demand high-temperature strength, corrosion resistance, and durability. They’re ideal for components in furnaces, heat exchangers, boiler parts, pressure vessels, and equipment used in petrochemical processing. Additionally, they play a crucial role in power generation, chemical plants, and industrial machinery, where reliable performance under thermal and mechanical stress is vital. With their excellent structural stability and long-lasting durability, these Stainless Steel 304H Bars and Rods offer dependable solutions for critical engineering, industrial, and high-temperature applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
