Neith Metals, based in Cairo, Egypt, has made a name for itself as a top-notch manufacturer and supplier of high-quality stainless steel products, catering to a variety of industrial and commercial sectors. Among their standout offerings are the Stainless Steel 317 Hex Bars and Rods, known for their remarkable corrosion resistance, durability, and mechanical strength. Crafted with precision and adhering to international standards, these hex bars and rods are built to thrive in tough and demanding conditions. Thanks to cutting-edge manufacturing technology and skilled craftsmanship, Neith Metals guarantees consistent quality, reliability, and performance, making them a go-to source for premium stainless steel solutions.
The Stainless Steel 317 Hex Bars and Rods are made from an austenitic alloy that includes 17–19% chromium, 11–13% nickel, and 3–4% molybdenum, with a carbon content of about 0.08%. In terms of mechanical properties, they boast a tensile strength of around 515 MPa, a yield strength close to 205 MPa, and an elongation of up to 40%, ensuring excellent toughness and stability. The addition of molybdenum significantly boosts their resistance to pitting, crevice corrosion, and oxidation at high temperatures. With their outstanding strength, corrosion resistance, and thermal stability, these Stainless Steel 317 Hex Bars and Rods promise reliable long-term performance in challenging industrial settings.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 317 | 0.08 max. | 18.0 – 20.0 | 2.00 max. | 11.0 – 14.0 | 0.045 max. | 0.03 max. | 1.00 max. |
| Element | Density | Melting Range,℃ | Tensile Strength | Yield Strength | Elongation | Hardness (Brinell) |
| SS 317 | 8 | 1454 ℃ | 515 | 205 | 40 | 217 |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
SS 317 hex bars/rods are commonly used in the industrial and construction sectors for their corrosion resistance and high strength. They are utilized in manufacturing chemical processing equipment, marine environments, heat exchangers, pumps, valves, fasteners, and structural components in corrosive conditions, ensuring durability and reliability.
SS 317 hex bars/rods typically range from 6 mm to 100 mm in size, with tolerances as per ASTM A276 or similar standards. Precise dimensions and tight tolerances ensure consistent strength, machinability, and fitment, making them ideal for high-performance applications in chemical, marine, and structural industries.
SS 317's chemical composition, with high levels of chromium (24-26%) and molybdenum (3-4%), enhances its resistance to pitting and crevice corrosion. The molybdenum content improves resistance to chloride-induced corrosion, while the balanced alloying helps prevent stress corrosion cracking, making it ideal for harsh, chloride-rich environments.
These hex bars and rods are widely utilized in industries that demand exceptional corrosion resistance, strength, and heat tolerance. They’re perfect for chemical and petrochemical plants, marine environments, and high-temperature industrial applications. Common applications include shafts, fasteners, valve components, structural parts, and machinery that face aggressive or corrosive conditions. Additionally, these hex bars and rods find their place in the food processing, pharmaceutical, and architectural sectors, where hygiene, strength, and durability are paramount. With their superior mechanical and corrosion-resistant properties, Stainless Steel 317 Hex Bars and Rods from Neith Metals offer long-lasting, low-maintenance solutions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
