Neith Metals, located in Cairo, Egypt, stands out as a top manufacturer and supplier of Stainless Steel 904L Hex Bars, known for their remarkable corrosion resistance, strength, and durability. The company is dedicated to crafting high-quality hex bars that adhere to international standards, catering to a diverse array of industrial needs. With state-of-the-art manufacturing facilities, precise engineering, and strict quality control measures, Neith Metals guarantees consistency and reliability in every product they offer. They serve crucial sectors like chemical, petrochemical, marine, and oil & gas industries, earning a solid reputation for excellence, innovation, and trustworthy stainless steel solutions both in Egypt and around the world.
Stainless Steel 904L Hex Bars are made up of chromium (19–23%), nickel (23–28%), molybdenum (4–5%), and copper, which together provide outstanding corrosion resistance and impressive mechanical strength. This alloy is particularly resistant to pitting, crevice corrosion, and stress corrosion cracking, even in harsh environments. These hex bars boast high tensile and yield strength, along with excellent toughness and ductility. Their low carbon content not only improves weldability but also maintains structural integrity, making Stainless Steel 904L Hex Bars perfect for demanding industrial applications that require durability, reliability, and top-notch performance under tough conditions.
| Specifications | ASTM B649 / ASME SB 649 |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Stainless Steel Round Bar | Outside Diameter in the range of 4mm to 500mm |
| Stainless Steel Bright Bar | Outside Diameter in the range of 4mm to 100mm |
| Stainless Steel Hex Bar | 18mm – 57mm (11/16″ to 2-3/4″) |
| Stainless Steel Square Bar | 18mm – 47mm (11/16″ to 1-3/4″) |
| Stainless Steel Flat Bar | 1/2″ to 10″ in thickness range of 2 mm to 150mm, Custom Size Stainless Steel Flats available |
| Range | 3.17 MM TO 350 MM DIA |
| Length | 1 to 6 Meters, Custom Cut Lengths |
| Finishing | Bright, Polish & Black |
| Form of | Hex, Wire (Coil Form), Wiremesh, Billet, Ingot, Forging Etc., |
| Other Services | Machining (CNC), Centreless Grinding (CG), Heat Treatment, Annealing, Pickling, Polish, Rolling, Forging, Cutting, Bending, Minor Fabrication, |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Cu | |
| SS 904L | Min | – | – | – | – | – | 19 | 4 | 23 | 1 |
| Max | 0.02 | 2 | 1 | 0.045 | 0.035 | 23 | 5 | 28 | 2 |
| Grade | Tensile strength (MPa) | Yield Strength 0.2% Proof(MPa) | Elongation (% in 50mm) | Hardness – Brinell |
| 904L | 490 | 220 | 36 | 70-150 |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
SS 904L Hex Bar offers excellent corrosion resistance, especially against pitting, crevice, and stress corrosion cracking. Its high nickel and chromium content make it ideal for harsh environments like chemical processing, marine, and power plants. The hexagonal shape provides enhanced strength and machinability, ensuring durability and reliability in industrial applications.
SS 904L outperforms many stainless steels, such as 304 and 316, in corrosion resistance due to its higher nickel and molybdenum content. This composition enhances resistance to chloride-induced pitting and crevice corrosion, making it ideal for environments with high chloride concentrations or acidic exposure, such as chemical and marine applications.
SS 904L Hex Bar is commonly used in the chemical, petrochemical, marine, and pharmaceutical industries. It is ideal for applications such as heat exchangers, reactor vessels, pressure vessels, and piping systems, where resistance to corrosion, especially in acidic and chloride-rich environments, is critical for long-term durability and performance.
You’ll find Stainless Steel 904L Hex Bars widely utilized in industries that demand high corrosion resistance and strength. In the chemical and petrochemical sectors, they’re commonly used in heat exchangers, valves, pumps, and reaction vessels. The marine industry relies on them for shafts, fasteners, and components that come into contact with seawater. In oil & gas applications, these bars are ideal for offshore platforms, pipelines, and equipment that must withstand challenging conditions. Moreover, Stainless Steel 904L Hex Bars are also employed in desalination plants, power generation, and the pharmaceutical industry, providing long-lasting durability, high performance, and dependable reliability.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Neith Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Alexandria, Egypt
