Titanium Gr 5 Forgings

Neith Metals, Alexandria, Egypt, is a leading manufacturer and supplier of high-quality Titanium Grade 5 Forgings. With its strong reputation for precision and excellence, the company specializes in making titanium components that offer unmatched strength, lightweight features, and superior corrosion resistance. The forgings are extensively used in demanding sectors like aerospace, automotive, and medical, where performance, reliability, and durability are of utmost importance. Here at Neith Metals, we are committed to providing tailored solutions in titanium that adhere to the highest international standards, ensuring each item surpasses clients’ expectations in terms of performance, quality, and long-term reliability.

Ti Alloy Grade 5 Upset Forging Exporter in Egypt, Ti Alloy Gr-5 Forging Supplier in Alexandria, Titanium Grade 5 Industrial Forgings Size Chart, UNS R56400 Titanium Rolled Forging Dealer in Cairo, Titanium Grade 5 Compression Forging Price in Alexandria, Stockist of Ti Alloy Grade 5 Hot Forging in Cairo, Titanium Grade 5 Cold Forging Supplier in Alexandria, Titanium Alloy Gr 5 Cold Forging Weight Chart, 3.7165 Ti Impression Die Drop Forging Price List in Egypt

Gr.5 Titanium Cold Forging

Ti Gr 5 Impression Die Drop Forging

Titanium Gr 5 Rolled Forging

What is Titanium Gr 5 Forgings?

Titanium Grade 5 Forgings (Ti-6Al-4V) consist of about 90% titanium, 6% aluminum, and 4% vanadium and include trace amounts of iron, carbon, and oxygen. This alloy provides an exceptional combination of strength, low weight, and corrosion resistance. It has tensile strength of around 930 MPa (135 ksi), yield strength of 830 MPa (120 ksi), and an elastic modulus of 113 GPa, with 10–15% elongation. Titanium Grade 5 has excellent resistance to fatigue, toughness, and superior performance when subjected to high temperature and pressure, and hence is very well suited for high-stress industrial applications.

ASME SB381 Ti Open Die Hammer Forging Stockist in Port Said, R56400Titanium Compression Forging Price List Cairo, Titanium Grade 5 Seamless Rolled Forging Manufacturer in Egypt, Titanium Gr 5 Open Die Forging Size Chart, Titanium Gr 5 Alloy Open Die Hammer Forging Exporter in Egypt, Titanium Grade 5 Impression Die Forging Price in Alexandria, Titanium Grade 5 Forging Dimensions, Ti Alloy 3.7165 Forgings Distributor in Egypt, Titanium Gr.5 Forgings Supplier in Cairo, Titanium Gr 5 Alloy Open Die Hammer Forging Exporter in Egypt

Titanium Gr 5 Forgings Specifications

Specifications	ASTM B381, ASME SB381
Standard	DIN, ASTM, BS and all International Standards
Flat bar blocks	up to 27″ width and 15,000 lbs
Cylinders and sleeves	up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs	up to 50″ diameter and 20,000 lbs
Rolled, hand forged or mandrel forged rings	up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts	up to 144″ maximum length and 20,000 lbs
Forging Types	Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging.

Chemical Compositions of Titanium Gr 5 Forgings

Grade	Ti	C	Fe	H	N	O	Al	V
Ti Grade5	90 min	–	0.25 max	–	–	0.2 max	6 min	4 min

Titanium Gr 5 Forgings Mechanical Properties

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
Titanium Gr. 5	4.43 g/cm3	1632 °C (2970 °F)	Psi – 138000 , MPa – 950	Psi – 128000 , MPa – 880	14 %

You Need Our Support, to Have Any Projects?

Test Certificate

Why Neith Metals?

Packaging

Equivalent Grades of Titanium Gr 5 Forgings

STANDARD	WERKSTOFF NR.	UNS
Titanium Gr. 5	3.7165	R56400

Modern Equipments

Expert Engineers

Well Maintained

Efficient Factories

Titanium Gr 5 Forgings Types

ASTM B381 Titanium Grade 5 Forgings Exporter in Alexandria, UNS R56400 Titanium Cold Forging Supplier in Port Said, Titanium Alloy Gr.5 Closed Die Forging Distributor Exporter in Egypt, Titanium Alloy Gr 5 Hot Forging Supplier in Cairo, TI Gr.5 Press Forgings Size Chart in Alexandria, Titanium Gr-5 Upset Forgings Size Chart in Egypt, DIN 3.7165 Titanium Forging Stockist in Cairo, Ti Alloy Grade 5 Forgings Supplier in Egypt, Titanium Gr.5 Forgings Supplier in Cairo

Frequently Asked Questions (FAQ)

What Factors Ensure The Durability Of Titanium Grade 5 Forgings?

Durability of Titanium Grade 5 forgings is ensured by proper heat treatment, controlled forging process, precise die design, alloy composition, and maintaining optimal surface finish, enhancing strength, corrosion resistance, and fatigue resistance.

What Industries Commonly Use Titanium Gr 5 Forgings?

Titanium Gr 5 forgings are commonly used in aerospace, automotive, medical, marine, and defense industries, providing high strength, corrosion resistance, and lightweight properties for critical components and high-performance applications.

What Is Closed-die Forging In Titanium Gr 5 Production?

Closed-die forging in Titanium Gr 5 production involves shaping titanium by compressing it between two shaped dies, ensuring precise dimensions, high strength, and improved material properties for demanding applications.

Titanium Gr 5 Forgings Uses

Titanium Grade 5 Forgings are widely applied in industries requiring high strength-to-weight ratio, corrosion resistance, and toughness. Aerospace industry uses them for turbine blades, airframe parts, and engine components because of their high strength and resistance to heat. The medical sector utilizes the alloy as surgical implants, dental appliances, and joint replacements because of its biocompatibility. In the automotive industry, it is utilized for high-performance structural and engine components. It also occurs in chemical processing hardware and sporting equipment. The superior fatigue resistance and stability of Titanium Grade 5 make it suitable for the most stringent applications.
